MIL-DTL-62460E
4.6.3.7 Clutch pressures, lube pressures, internal leakage, and input torque. To determine
conformance to 3.4.11, 3.4.12, 3.4.13, 3.4.14, 3.4.4.c, 3.4.4.d, 3.4.18.2, 3.4.18.3 and 3.4.18.4:
a. Apply 56 to 76 L/min flow into lube port L.
b. Apply 1830 +35 kPa to control port M and hold that pressure.
c. At the forward (CW) input speeds and at the reverse (CCW) input speed listed in
table XI, in both the geared steer and clutch brake modes, observe that the
requirements as specified in table XI are met at each steer lever position indicated
in tables IV and V.
TABLE XI. Requirements for test in 4.6.3.7.
Information to be observed
Pressure
Pressure
Input
at each
at each
shaft
of the 6
Pressure
of the 6
Flow
No load
speed
clutch
at lube
lube test
req'd
input
(rpm)
test ports
port L
ports
at port M
torque
0
3.4.11 and
3.4.12 and
3.4.4.c
3.4.13
3.4.14 and
Geared
2500 +50 CW
table IV
table IV
table IV
Steer
750 +50 CCW
3.4.18.2 and
3.4.18.3 and
3.4.4.d
3.4.18.8 and
(reverse)
table IV
table IV
table V
0
3.4.11 and
3.4.12 and
3.4.4.c
3.4.13
3.4.14 and
Clutch
1800 +50 CW
table V
table V
table V
Brake
750 +50 CCW
3.4.18.2 and
3.4.18.3 and
3.4.4.d
3.4.18.4 and
(reverse)
table V
table V
table V
4.6.3.8 Brakes. To determine conformance to 3.4.15:
a. Apply 56 to 76 L/min flow into lube port L.
b. Apply 1830 +35 kPa to control port M and hold that pressure.
4.6.3.9 Output performance, high torque and high power. To determine conformance to
3.4.16 and 3.4.18.5.
a.
Apply 56 to 76 L/min flow into lube port L.
b.
Apply 1380 +35 kPa to control port M and hold that pressure.
c.
Couple each output shaft to a dynamometer.
d.
Place control into the geared steer mode or clutch brake mode as specified in
table IV.
16
