MIL-DTL-45334E
M
45334 -
XX
Type (see 1.2).
1 - Type I compressor - M45334-1
2 - Type II compressor - M45334-2
3 - Type III
4 - Type IV
5 - Type V
6 - Type VI
7 - Type VII
8 - Type VIII
9 - Air cleaner for type I and II compressors
10 - Governor for type I and II compressors
Specification number.
Prefix for military specification.
6.5 Airbrake system evaporator. The evaporator assembly should be used in conjunction
with types I, II, III, IV and V compressor systems. As this assembly is not an essentially integral
part of any compressor system and is to be utilized only in cold (below -35°F (-37°C))
atmospheric conditions, no qualification of this assembly is required. However, prior to
installation on any vehicles, the following precautions should be followed:
a. Fill the jar two-thirds full with 188 proof commercial pure methyl alcohol.
b. The compressor to alcohol evaporator line shall be less than 5 ft long and
protected from excessive heat, where applicable.
c. Activate the compressor and note air bubbles in alcohol evaporator. Presence of
bubbles indicates unit is operating properly.
6.6 Changes from previous issue. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
Custodians:
Preparing Activity:
Army - AT
Army - AT
Navy YD2
Air Force - 99
(Project 2530-0421)
Review Activities:
Army - MI
Navy - MC
DLA - CC
19
