MIL-DTL-13719G
TABLE VI. First article inspections.
Inspection
Requirement paragraph
Test method
Visual inspection
Constriction
Proof pressure
Expansion resistance
Bursting strength
Fatigue life
Low temperature flexibility
Tensile strength
Ozone resistance
Fluid resistance
Salt spray
TABLE VII. First article test sequence.
Sample
Requirement
Inspection
Test method
number
paragraph
All
Visual inspection
Constriction 1/
Proof pressure
1, 2, 3, 4
Fatigue life
Expansion resistance
5, 6
Bursting strength
Fluid resistance
7, 8
Ozone resistance
Low temperature flexibility
9, 10
Constriction 1/
Proof pressure
11, 12
Tensile strength
Constriction
13, 14, 15, 16
Salt spray
1/ If it is necessary to cut the hose assembly to perform this test, perform this test on one additional
sample and not on samples 1, 2, 3, 4 or 9 and 10. This may occur if a specific configuration is
required because of an OEM drawing. If doing hose inspections only use a hose assembly
configuration that does not require it to be cut.
4.3.5 Lot records. The manufacturer or supplier shall, on request, furnish to the purchaser a
certificate stating that each lot has been sampled, tested, and inspected in accordance with
MIL-DTL-13719 or the applicable hose assembly drawing for type I or type II hose or hose assemblies
and has met the requirements. Manufacturers shall monitor for compliance to the prescribed procedures,
and observe that satisfactory manufacturing conditions and records on lots are maintained for these
pipes. The records, including as a minimum, an attributes summary of all quality conformance
inspections conducted on each lot, shall be available to review by customers at all times. Manufacturers
shall keep lot records for 3 years minimum.
9
