INCH-POUND
MIL-DTL-13719G
30 August 2012
SUPERSEDING
MIL-DTL-13719F
18 June 2007
DETAIL SPECIFICATION
HOSE AND HOSE ASSEMBLY, RUBBER,
HYDRAULIC BRAKE, TYPE I AND TYPE II
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers hose and hose assembly, rubber, hydraulic brake, type I and
type II.
1.2. Part or Identifying Number (PIN). The PIN consists of the letter M, the basic specification number,
a dash, a number for hose type, a number for hose size, a dash, three numbers for length a dash, and a
number for fractions of an inch or for bulk hose lengths the letter B or S.
M
13719 -
1
-3 -
096
-
6
Fractional lengths in 1/8 inch increments (1 thru 7),
see 1.2.3.2 or B or S for bulk lengths, see 1.2.3.3
Length in inches or feet (see 1.2.3.1 or 1.2.3.3)
Sizes (see 1.2.2)
Type (see 1.2.1)
Specification number
M prefix
1.2.1 Type. Type designator and characteristics, see table I.
TABLE I. Type and characteristics.
Designator
Type
Characteristics
1
Type I
Regular expansion
2
Type II
Low expansion
Comments, suggestions, or questions on this document should be addressed to: Defense Supply Center,
Columbus, Attn: VAI, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to fluidflow@.dla.mil. Since
contact information can change you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.dla.mil.
AMSC N/A
FSC 2530
