A-A-57174A
PA 9111-5094 or https://assist.daps.dla.mil/quicksearch/. The FAR may be obtained from
6.1.2 Non-Government publications. ASTM B633, "Standard Specification for
Electrodeposited Coatings of Zinc on Iron and Steel"; ASTM D3951 "Standard Practice for
Commercial Packaging", can be obtained from the American Society for Testing and Materials,
1916 Race Street, Philadelphia, PA 19103-1187 or www.astm.org. Copies of Institute of
Electrical and Electronic Engineers (IEEE) standards may be obtained at www.ieee.org or are
available from IEEE Operations Center Sales Office, 445 Hoes Lane, PO Box 1331, Piscataway,
NJ, 08855-1331 or www.ieee.org.
6.2 Ordering data. Acquisition documents must specify the following:
a.
Title and date of this commercial item description.
b.
If required, the specific issue of individual documents referenced (see 6.1).
c.
Part or identification number [PIN (see figure 1)].
d.
Selection of applicable level and packaging requirements (see 5).
6.3 Part-or Identifying Number (PIN). The PIN to be used for nut, cap acquired to this
commercial item description is created as follows:
A 57174 - X
Thread designation:
1 - left hand thread
2 - right hand thread
CID number
Designates a CID
6.4 Cross-reference data. Nut, caps conforming to this CID are interchangeable/substitutable
with nut, caps conforming to MS53068C (see figure 1).
6.5 Metric product. Nut, caps manufactured to metric dimensions will be considered on the
following basis:
a. Products manufactured to metric dimensions will be considered on an equal basis
with those manufactured using inch-pound units, provided they fall within specified
tolerances using conversion tables contained in the latest revision of
IEEE/ASTM SI10, and all other requirements of this CID are met.
b. If a product is manufactured to metric dimensions and those dimensions exceed the
tolerances specified in the inch/pound units, a request should be made to the
contracting officer to determine if the product is acceptable.
c. The contracting officer has the option of accepting or rejecting the product.
3
